EM30 Specs
- 12 VDC System with Heavy Duty Group 31 Battery
- On Board Battery Charger
- Fork Lift Loadable
- Net Weight – 925 lbs. (420 kilo)
- Approx 18′ working height
- Two man capacity
- 500 lbs capacity
- Easily removed for storage
- Self powered with charger
- 60″ x 30″ working platform
- Quick and easy manual leveling
- Can be leveled to lift on uneven ground up to 12 degrees
- Can be fitted to a variety of UTV’s
- Four Standard Jacks included
- Electric Jacks are optional
- Built in safety features to prevent misuse
Operating Dimensions
- 18′ max work height (5.5m)
- 12′ max platform height (3.7m)
- 500 lbs. safe work load (226.8kg)
Platform Dimensions
- 30″ Length (76cm)
- 60″ Width (152cm)
- 45″ Guard Rail Height (115cm)
- 4″ Toe Board (10cm)
Safety Features
- Visual & Audible Alarms & Lockout
- Outrigger Legs for Stability
- Non-slip Platform & Steps
- Overload Alarm & Lockout
- Tilt Alarm & Lockout
- Stability Alarm & Lockout
- Emergency Lowering Valve
- Emergency Stop
- Push to Enable Function
Easy on and off
It takes less than 3 minutes to remove
and store the EM. There are just two bolts.
EM Options and Accessories
- Electric Jacks
- Electric Jack Guards
- Utility Box
- Tail Lights
- Fenders
